Vertical Assembly Stand

Vertical Assembly Stand

Assembly stand for vertical assembly

Category: Tags: , , , , , , , , Teknik Bilgiler:   <p>Length 3.110 mm<br /> Width 1.200 mm<br /> Vertical height 2.050 mm<br /> Pneumatic height adjustment 500 mm<br /> Roller conveyor width 200 mm<br /> Weight 330 kg<br /> Carrying capacity 300 kg<br /> Air pressure: 7 bar<br /> Air consumption approx. 35 l / min.</p>

Assembly table for vertical assembly

Durable steel construction
Ideal for vertical mounting
Suitable for lines
Stepless intermediate positions for ergonomic work
Height adjustment with pneumatic cylinder
Steel reel support
Bench surface with plastic guide rails
2 profile vices that can be slid horizontally
4-way compressed air connection

Length 3.110 mm
Width 1.200 mm
Vertical height 2.050 mm
Pneumatic height adjustment 500 mm
Roller conveyor width 200 mm
Weight 330 kg
Carrying capacity 300 kg
Air pressure: 7 bar
Air consumption approx. 35 l / min.
